CB182K0224KBC datasheet by Kyocera AVX Components

CB182K0224KBC Frequently Asked Questions (FAQs)

• What is the recommended land pattern for CB182K0224KBC?
  The recommended land pattern for CB182K0224KBC is a rectangular pad with a size of 2.5mm x 1.25mm, with a solder mask clearance of 0.1mm.
• How do I handle the component during assembly to prevent damage?
  Handle the component by the edges, avoid touching the ceramic body or the terminations, and use an anti-static wrist strap or mat to prevent electrostatic discharge (ESD) damage.
• What is the maximum reflow temperature for CB182K0224KBC?
  The maximum reflow temperature for CB182K0224KBC is 260°C, with a peak temperature of 240°C for a maximum of 20 seconds.
• Can I use CB182K0224KBC in a high-vibration environment?
  Yes, CB182K0224KBC is designed to withstand high-vibration environments, but it's recommended to follow the manufacturer's guidelines for vibration testing and to ensure proper mounting and soldering.
• How do I store CB182K0224KBC components to prevent moisture absorption?
  Store CB182K0224KBC components in a dry, cool place, away from direct sunlight, and in their original packaging or a sealed bag with desiccant to prevent moisture absorption.
